Epson · Wide-Format Plotter

Epson SureColor SC-P9000 STD

44" color graphics & photo printer

ModelC11CE40301A0
Prints44" wide
Score66/100

Authorized Epson dealerGenuine hardware & ink

Manufacturer warrantyExtension plans available

Free shippingContinental U.S.

Plotter specialistsAEC experts, not just sellers

Analyst take

An eleven-channel UltraChrome HDX printer with Orange and Green inks, built for color fidelity over plotting speed.
The 3.5-picoliter drop and 2880 x 1440 DPI ceiling suit renderings, boards and proofs on coated and photo media.
A single 44-inch roll and Photo/Matte black swapping make it poorly suited to high-volume monochrome bid sets.

Not sure if the C11CE40301A0 is right for you?

Compare key specs and an AI analyst read-out against similar models.

Compare printers →

Wide-format reach Prints up to 44" wide on rolls and sheets.
Fine detail 2880 x 1440 DPI maximum resolution for crisp line work.
Ink platform Light black, Light light black, Photo black, Matte black, Cyan, Light Cyan, Yellow, Vivid magenta, Vivid light magenta, Orange, Green.
Analyst score Scores 66/100 in our class-relative rating.

Overview

Built for the work

Epson SureColor SC-P9000 STD, Inkjet, 2880 x 1440 DPI, ESC/P-R, Light black, Light light black, Photo black, Matte black, Cyan, Light Cyan, Yellow, Vivid magenta,…, 700 ml, PrecisionCore

Spec Analysis
overall

Where it performs best

Color 89

Print Quality 82

Media Handling 80

How we grade →

Expert analysis

What you should know

By Priya VenkatesanColor & Imaging Editor

Key takeaways

An eleven-channel UltraChrome HDX printer with Orange and Green inks, built for color fidelity over plotting speed.
The 3.5-picoliter drop and 2880 x 1440 DPI ceiling suit renderings, boards and proofs on coated and photo media.
A single 44-inch roll and Photo/Matte black swapping make it poorly suited to high-volume monochrome bid sets.
Optional SpectroProofer M1 44" and ILS30EP spectrophotometer support genuine color-managed proofing.
Three-black gray ramp (Light Black, Light Light Black) yields smoother neutrals and less banding in shadows.
For production plan runs, the dual-roll P8570DR or multifunction SC-P8500DM are the better in-family fit.

The Epson SureColor SC-P9000 STD is a 44-inch, eleven-channel photographic printer that keeps drifting into AEC print rooms for a specific reason: it renders color the way a rendering deserves. Where most wide-format plotters treat a saturated red as a checkbox, this machine treats it as a place a photograph lives — the difference shows up in the last five percent of a sky, or in the way a rendered brick façade holds its warmth instead of going orange.

But let’s be honest about what it is and isn’t. This is a proofing-and-presentation printer with an AEC side job, not a bid-set workhorse. If your day is measured in linear feet of black-line D-size drawings, read on carefully — the fit is narrower than the width suggests.

A0 (33" x 47" (841 x 1189 mm))Max print size44-inch roll width

3.5 plInk dropPrecisionCore head

2880 x 1440 DPIMax resolution

700 mlInk setUltraChrome HDX, 11 channels

What the eye actually sees

The SC-P9000 STD carries eleven UltraChrome HDX inks, including Orange and Green alongside the usual CMYK, plus a three-black gray ramp — Light Black and Light Light Black riding under Photo or Matte Black. In plain terms: broader saturation where it matters and smoother neutral transitions where banding usually betrays a cheaper machine. On a presentation board, that means a dusk elevation whose shadows stay a believable blue-gray rather than muddying toward brown, and skin tones in a lobby render that hold together instead of turning waxy.

The 3.5-picoliter drop and 2880 x 1440 DPI ceiling are Epson’s figures, and they translate into fine detail on coated and photo media. Note the eleven channels share Photo and Matte black by swapping — a step that costs ink and time on jobs that mix glossy proofs and matte boards.

Where it fits in AEC work

This machine earns its footprint in visualization and client-facing output, not production plotting. It’s a strong fit for firms whose deliverables include large-format renderings, competition boards, marketing imagery, and — for the studios that also do reprographic or fine-art work — color-managed proofing. The optional color-accurate workflow deepens with the SpectroProofer M1 44″ and ILS30EP spectrophotometer add-ons, which let you calibrate and verify rather than eyeball.

Presentation and competition boards — large renderings where color credibility wins the room
Marketing and business-development imagery printed in-house on gloss or canvas media
Color-managed proofing for firms with a reprographics or fine-art sideline
Site and aerial photography, GIS maps where photographic depth reads better than line-plotter color

Where it's the wrong tool

If your volume is bid sets, permit packages and as-builts — high-count monochrome plans on plain bond — a photographic single-roll printer is an expensive, slow way to solve that problem. You’d want a production-oriented plotter, and within Epson’s own family the dual-roll Epson P8570DR 44-in or a multifunction like the SC-P8500DM 44-in with its scanner and second roll fit far better for unattended, mixed-size plan runs.

Conversely, if color fidelity is the whole point and you want the current-generation platform, look at the Epson SC-P9500 44-in step-up before committing. And if you’re weighing this against its own siblings, put the two side by side before you sign.

Compare and dig deeper

Epson SC-P9500 44-inThe current-generation fidelity step-up in the same family.Epson P8570DR 44-inDual-roll sibling built for production plan runs, not photography.44-inch class rankingSee where this machine sits among current wide-format peers.

The read

The SureColor SC-P9000 STD is a specialist that occasionally moonlights in AEC. Buy it because your work is judged on color — renderings, boards, proofs, photography — and you want eleven inks doing the seeing. Don’t buy it as a plan plotter; the single roll, the black-ink swap and the deliberate pace all point away from high-count drawing production. If that fidelity-first description is your firm, it’s a well-matched, still-current choice. If it isn’t, the dual-roll and multifunction siblings will serve you longer and cheaper per drawing.

Spec analysis

How the specs grade

Overall performance

within color graphics & photo printers

76% spec coverage

This printer

How it scores

Media Handling80

Print Quality82

Print Cost79

Color89

SpeedNot enough spec data

Connections67

Workflow0

Size / Fit55

WarrantyNot enough spec data

Graded on a curve against the best published spec among the wide-format printers we track — 100 = the catalog’s gold standard for that metric (the finest droplet, the longest warranty, the fastest rated speed actually on the market). Every input is a manufacturer-published spec; rated speeds are shown as listed, not timed throughput. Ticks mark the class best. How we grade →

Verified specifications

The specs that decide it

Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Printing colors	Light black, Light light black, Photo black, Matte black, Cyan, Light Cyan, Yellow, Vivid magenta, Vivid light magenta, Orange, Green
Page description languages	ESC/P-R
Internal memory	1024 MB
Maximum print size	A0 (841 x 1189 mm)
Media thickness	0.08 – 1.5 mm
Sound level (printing)	47 dB
Power consumption	75 W

Specifications

Full technical detail

Print technologyInkjet

Max resolution2880 x 1440 DPI

Max print width44"

ColorColor

ConnectivityEthernet (Gigabit LAN), USB

Use casePhoto / Fine Art

Printing

Color	Yes
Print head	PrecisionCore
Printing colors	Light black, Light light black, Photo black, Matte black, Cyan, Light Cyan, Yellow, Vivid magenta, Vivid light magenta, Orange, Green
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Print head nozzles	360 nozzles black,360 nozzles per colour
Borderless printing	Yes
Page description languages	ESC/P-R
Print cartridge volume (metric)	700 ml

Performance

Display	LCD
Color display	Yes
Product color	Black, Gray
Internal memory	1024 MB
Built-in display	Yes
Country of origin	China
Sound pressure level (printing)	47 dB

Paper handling

Cut sheets	Yes
Roll paper	Yes
Media thickness	0.08 – 1.5 mm
Roll top margin	0.118" (3 mm)
Maximum print size	A0 (841 x 1189 mm)
Media width (rolls)	1117.6 mm
Paper tray media types	Thick paper
Print margin cut-sheet	3 x 3 x 14 x 3
ISO A-series sizes (A0…A9)	A0, A1, A2, A3, A3+, A4
ISO B-series sizes (B0…B9)	B0, B1, B2, B3, B4

Ports & interfaces

USB port	Yes
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	Gigabit

Weight & dimensions

Depth	26.3" (667 mm)
Width	73.4" (1864 mm)
Height	48" (1218 mm)
Weight	429.9 lbs (195 kg)

Power

AC input voltage	100-240 V
AC input frequency	50 – 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	2 W
Power consumption (typical)	75 W

Other features

Ink drop	3.5 pl
Power source	AC 100 V – 240 V,50 Hz – 60 Hz

Logistics data

Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Packaging data

Manual	Yes
Package depth	80.3" (2040 mm)
Package width	32.7" (830 mm)
Package height	42.9" (1090 mm)
Package weight	438.7 lbs (199 kg)
Drivers included	Yes

System requirements

Compatible operating systems	Linux, Mac OS 10.9.x, Mac OS X 10.11.x, Mac OS X 10.12, Mac OS X 10.12.x, Windows 10, Windows 2000, Windows 7, Windows 7, 64-Bit-Version, Windows 8 (32/64 Bit), Windows 8.1, Windows Server 2003 (32/64 Bit), Windows Server 2008 (32/64 Bit), Windows Server 2008 R2, Windows Vista, Windows Vista, 64-Bit-Version, Windows XP, Windows XP, 64-Bit-Version
Linux operating systems supported	Yes

Everything that fits the Epson SureColor SC-P9000 Violet Spectro

The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.

58 ink cartridges · 122 paper & media items · 7 accessories · 3 coverage plans

Epson SureColor SC-P9000 Violet Spectro ink and paper →

Supplies

Compatible ink, printheads & media

Genuine consumables that fit the Epson SureColor SC-P9000 STD — only the cartridges, printheads and media compatible with this model.

Questions

Straight answers

Is the SC-P9000 STD a good bid-set or permit-set plotter?

Not really. It’s a single-roll photographic printer tuned for color fidelity, so high-count monochrome plan production runs slower and costs more per sheet than a dedicated plotter. The dual-roll Epson P8570DR or multifunction SC-P8500DM suit that work far better.

What ink does it use, and how many colors?

It uses Epson UltraChrome HDX inks in an eleven-channel set — including Orange and Green plus Light Black and Light Light Black — available in 700 ml cartridges. Photo Black and Matte Black share a channel and swap depending on media.

Can it handle color-managed proofing?

Yes. It supports the optional Epson SpectroProofer M1 44″ and the ILS30EP spectrophotometer for calibrated, verifiable color, which is why some reprographics and fine-art operations choose it alongside AEC visualization work.

How does it connect and what does it support?

It offers Gigabit Ethernet and a USB Type-A port, uses the ESC/P-R page description language, and supports Windows, macOS and Linux. An optional Hard Disk Unit is available for the T and P series.

How wide can it print?

It accepts media up to 44 inches wide and prints up to A0 (33″ x 47″), handling roll and cut-sheet media from 0.003″ to 0.059″ thick, including thick papers and canvas.

Should I consider a newer model instead?

If color fidelity is your priority and you want the current-generation platform, look at the SC-P9500 44-in step-up before deciding. Comparing the two side by side is worthwhile before committing.
