HP DesignJet 110plus r

The machine’s compact footprint is its clearest operational advantage. At 41 inches wide, 21.1 inches deep, and 50.7 pounds, it is easier to place near a project team than a floor-standing production plotter. The LCD and USB Type-A port also give an operator a direct, local way to work with the device. There is one USB 2.0 port and one parallel port, so buyers should confirm how that connectivity fits the office’s current network and print-submission setup before installation.

For AEC use, think short-run color drawings, GIS extracts, coordination sheets, proofing, and presentation-oriented output on bond, coated, matte, glossy, semi-glossy, or proofing paper. A 150-sheet input capacity and 50-sheet output capacity are useful for routine office work. They are not an unattended set-production system. The failure mode is simple: output accumulates, someone gets busy, and the printer becomes tomorrow morning’s problem.

Bottom line: This is most at home close to a design or project team producing modest, varied output rather than feeding a deadline-driven print room.

The HP 110plus r uses thermal inkjet technology, a four-cartridge ink system, PCL 3, and 64 MB of internal memory. Its stated maximum resolution is 1200 x 600 DPI. Those facts point to a machine intended for ordinary color documents and graphics where readable text, visible markups, and usable color differentiation matter. They do not, by themselves, prove how a particular CAD PDF, dense raster map, or complex BIM export will process. Test the files that cause trouble now, not the clean sample PDF the dealer happens to have handy.

Roll margins are stated at 0.197 inches, while cut-sheet margins are 0.2 x 0.47 inches. That deserves attention for title blocks, border lines, and documents designed close to the edge. The printer also supports an optional HP Designjet 110/120/130 Auto Roll Feed accessory, which may be relevant where roll output is part of the routine.

Bottom line: Check the printable-area requirement and run representative drawings before treating it as a production-standard plotting device.

The nearest named in-family comparison available here is the HP DesignJet T918 36-in. That catalog entry is described as a 36-inch scanner/MFP and is labeled discontinued. Its integrated scanning and copying role is materially different from this printer-only device, particularly for teams handling redlines, legacy drawings, or repeated copy workflows. If scan-to-file and copy-to-print are daily work, that function matters more than a tidy desktop footprint.

The listed Epson alternatives are 64-inch devices, so they occupy a different size class. The comparison view with the Epson F9470 64-in can help show the scale difference, but it should not be read as a like-for-like AEC replacement decision. A wider machine changes media handling, floor space, and the kind of work the department can bring in-house.

For a broader placement within its category, see the class ranking. Bottom line: Choose this machine for its compact, smaller-format role; choose a scanner/MFP or wider platform only when that workflow is genuinely the work.
