Home / Wide-Format Printers / HP DesignJet
HP · Wide-Format Plotter
HP DesignJet 100plus
technical / CAD plotter
- Model100plus
Authorized HP dealerGenuine hardware & ink
Manufacturer warrantyExtension plans available
Free shippingContinental U.S.
Plotter specialistsAEC experts, not just sellers
Analyst take
- The HP 100plus is a compact color thermal-inkjet printer intended for attended, modest-volume document output.
- Its 1200 x 600 DPI maximum resolution is the specification most relevant to readable technical linework and color documents.
- A single tray with 70 sheets of input capacity makes paper changes and longer runs an operator-managed process.
Not sure if the 100plus is right for you?
Compare key specs and an AI analyst read-out against similar models.
Overview
Built for the work
HP Designjet 100plus, Thermal inkjet, 1200 x 600 DPI, PCL 3, Black, Cyan, Magenta, Yellow, 70 sheets, 50 sheets
Expert analysis
What you should know
Key takeaways
- The HP 100plus is a compact color thermal-inkjet printer intended for attended, modest-volume document output.
- Its 1200 x 600 DPI maximum resolution is the specification most relevant to readable technical linework and color documents.
- A single tray with 70 sheets of input capacity makes paper changes and longer runs an operator-managed process.
- The listed absence of USB and Ethernet LAN means IT should verify the connection and submission workflow before deployment.
- The HP DesignJet T918 36-in is the listed in-family alternative when scanning and copying are required.
- The Canon GP-4000 44-in is a listed comparison point for teams whose requirement is wider output.
It is 4:45 p.m., somebody needs a readable drawing set, and the last thing the print room needs is a machine demanding a ceremony. The HP 100plus is a compact color thermal-inkjet printer for modest technical-document work: marked-up sheets, small plan excerpts, color coordination pages, and presentation material where four-color output helps separate one trade from another.
This is not a modern networked plot-room hub. It has no USB port or Ethernet LAN listed, one input tray, and a 70-sheet input capacity. That makes it a machine for contained, local workflows—not an unattended department queue with five people sending PDFs at once. Small is useful. Small also fills up quickly when a permit set lands.
1200 x 600 DPIMaximum resolutionUseful context for linework and color document output.
70 sheetsTotal input capacityOne tray means media changes remain an operator task.
50 sheetsTotal output capacityWatch the tray during longer runs.
48 WPower supplyA low-power desktop-scale device rather than a production-room machine.
Where it fits in an AEC office
The HP 100plus makes the most sense where documents are printed in short bursts and somebody is nearby to load paper, collect output, and keep the job moving. It supports plain, coated, and glossy paper in its tray, so an architect can shift from ordinary coordination sheets to a presentation page without adding another device. Its listed A-series support includes A1, A2, and A4.
For line drawings, the relevant specification is the stated 1200 x 600 DPI maximum resolution. That does not settle whether every PDF will look right; file construction, driver settings, and paper still get a vote. But it gives this printer a reasonable technical-document role where legibility matters more than high-volume automation.
Bottom line: It fits a small, attended color-document workflow better than a busy shared print queue.
Paper, ink, and the operator’s part of the bargain
This printer uses four cartridges: black, cyan, magenta, and yellow. Compatible supplies include HP 10, HP 11, HP C7029A, and HP C7031A. Supported media options include HP C1853A, HP C6818A, HP C6821A, HP C6984A, HP CHP510, and HP glossy and premium photo papers.
The failure mode is not mysterious. A 70-sheet input tray and 50-sheet output capacity can be perfectly adequate for a few sheets, then become a bottleneck when several people arrive with documents at once. There is only one input tray. That means changing between plain bond, coated sheets, and glossy media is manual. No machine can save a deadline from paper loaded for the previous job. I have tried.
Bottom line: The consumable and media choices support varied short-run work, but the tray arrangement rewards an operator who plans ahead.
What to compare before you commit
The HP 100plus is 41 inches wide, 16.3 inches deep, 8.7 inches high, and weighs 48.5 lbs. Those dimensions favor locations where floor space is tight. Its PCL 3 page-description language and bundled HP Designjet System Maintenance software point to a straightforward device-management arrangement, but the listed absence of USB and Ethernet LAN matters. IT should confirm the actual connection path and supported submission workflow before putting it into service.
If scanning and copying are part of the daily requirement, the listed in-family alternative is the HP DesignJet T918 36-in. It is identified as a scanner/MFP, which is a different job from print-only output. If wider 44-inch output is the issue, compare the HP 100plus with the Canon GP-4000 44-in or use the side-by-side comparison. Width alone does not make a better workflow; it only makes a wider sheet possible.
Bottom line: Choose this printer for compact, attended output—not because a larger or multifunction device sounds reassuring on a procurement form.
Compare the workflow, not just the hardware
The read
The HP 100plus is a compact four-color technical printer with a clear place in low-volume, attended AEC output. It can handle plain, coated, and glossy paper, and its stated 1200 x 600 DPI resolution is relevant to readable drawings and color-coded documents. The trade-off is operational, not subtle: one tray, limited input and output capacity, and no listed USB or Ethernet LAN. For a small office printing selected sheets near the desk, that can be acceptable. For a deadline-driven print room producing mixed stacks, scanning originals, or serving a networked team, it is likely the wrong tool. Bottom line: Buy it for controlled short runs, not for the afternoon when everyone discovers the bid is due today.
Spec analysis
How the specs grade
Overall performance
—Not enough data for an overall score
Individual dimensions are shown where the specs support them.
- This printer
- Epson SureColor T3475
Category leaders best technical / CAD plotters, by dimension
Verified specifications
The specs that decide it
| Print technology | Thermal inkjet |
|---|---|
| Maximum resolution | 1200 x 600 DPI |
| Printing colors | Black, Cyan, Magenta, Yellow |
| Number of print cartridges | 4 |
| Page description languages | PCL 3 |
| Internal memory | 64 MB |
| Ethernet | No |
Specifications
Full technical detail
Print technologyThermal inkjet
Max resolution1200 x 600 DPI
ColorColor
Use caseCAD / Technical
Printing
| Color | Yes |
|---|---|
| Printing colors | Black, Cyan, Magenta, Yellow |
| Print technology | Thermal inkjet |
| Maximum resolution | 1200 x 600 DPI |
| Number of print cartridges | 4 |
| Page description languages | PCL 3 |
Performance
| Internal memory | 64 MB |
|---|
Paper handling
| Paper tray media types | Coated paper, Glossy paper, Plain paper |
|---|---|
| ISO A-series sizes (A0…A9) | A1, A2, A4 |
Ports & interfaces
| USB port | No |
|---|---|
| Ethernet LAN | No |
Weight & dimensions
| Depth | 16.3" (414 mm) |
|---|---|
| Width | 41" (1041.4 mm) |
| Height | 8.7" (221 mm) |
| Weight | 48.5 lbs (22 kg) |
Power
| Power supply | 48 W |
|---|
Packaging data
| Bundled software | HP Designjet System Maintenance |
|---|
Input & output capacity
| Total input capacity | 70 sheets |
|---|---|
| Total output capacity | 50 sheets |
| Maximum input capacity | 70 sheets |
| Maximum output capacity | 50 sheets |
| Maximum number of input trays | 1 |
Everything that fits the HP DesignJet 100plus
The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.
9 ink cartridges · 4 printheads · 26 paper & media items · 1 accessory
HP DesignJet 100plus ink and paper →Supplies
Compatible ink, printheads & media
Genuine consumables that fit the HP DesignJet 100plus — only the cartridges, printheads and media compatible with this model.
Ink Cartridges 9
Printheads 4
Paper & Media 26
Representative image11 Mil Water-Resistant Synthetic BannerRepresentative image180gsm Solvent Satin PE PaperRepresentative image5 Mil Polycarbonate LaminateRepresentative image3 Mil Fusion Finesse Polypropylene LaminateRepresentative image230gsm Special Matte Photo PaperRepresentative image200gsm Special Matte Photo PaperRepresentative image10 Mil Water-resistant Blockout Display FilmRepresentative image10 Mil White Opaque BackerRepresentative image8mil Poster Paper Satin (514)Representative image20LB Engineering Vellum (471)Representative imageWSL 28LB Simple Inkjet Coated Matte Paper (C2S) (448)Representative imageWSL 24LB Simple Inkjet Coated Matte Paper (C2S) (446)
HP photo-quality paper, semi-glossy, two-sided, A4 (25 sheets)
HP C6821A printing paper A3 (297×420 mm) Gloss 50 sheets White
HP C6818A printing paper A4 (210×297 mm) Gloss 50 sheets White
HP C1853A printing paper A4 (210×297 mm) Matte 100 sheets White
HP Q1961A large format media
HP Q1962A large format media
HP Q1967A printing paper A3+ (330×483 mm) Matte 100 sheets White
HP Premium Plus Inkjet Transparency Film-20 sht/A4/210 x 297 mm
HP Premium Plus Inkjet Transparency Film-50 sht/A4/210 x 297 mm
HP Q2519A photo paper
HP Premium Plus High-gloss A3 White
HP Gloss Proofing Paper 173 g/m²-A1+/610 mm x 914 mm-20 sheets large format media
HP Advanced Paper 80 g/m²-A4/210 x 297 mm/500 sht printing paper
HP Glossy Photo Paper-20 sht/A3/297 x 420 mmAccessories 1
Questions
Straight answers
Is the HP 100plus a good fit for CAD and technical drawings?
It is a color thermal-inkjet printer with a stated maximum resolution of 1200 x 600 DPI and PCL 3 support. It is most appropriate for short, attended technical-document jobs where line readability and color coding matter.
Can it handle different paper types?
Its paper tray supports plain, coated, and glossy paper. With one input tray, changing media types is a manual step between jobs.
How much paper can it hold?
The total and maximum input capacity are 70 sheets, with a total and maximum output capacity of 50 sheets. That is workable for short runs but calls for attention during larger batches.
Does it connect by USB or Ethernet?
The listed specifications show no USB port and no Ethernet LAN. Confirm the practical connection method and job-submission arrangement with IT before deployment.
Which inks are compatible with the HP 100plus?
The resolved compatible ink families are HP 10, HP 11, HP C7029A, and HP C7031A. The printer uses four cartridges: black, cyan, magenta, and yellow.
When should I consider the HP DesignJet T918 36-in instead?
Consider the HP DesignJet T918 36-in when scanning and copying are part of the workflow, since it is listed as a scanner/MFP. The HP 100plus is the simpler print-focused choice.
