HP · Wide-Format Plotter
HP DesignJet T1600
36" color graphics & photo printer
- ModelT1600
- Prints36" wide
- Score68/100
Authorized HP dealerGenuine hardware & ink
1-year warranty includedExtendable to 5 years
Free shippingContinental U.S.
Plotter specialistsAEC experts, not just sellers
Analyst take
- The 36-inch format and 2400 x 1200 DPI specification suit detailed AEC drawings and color-coded review documents.
- PostScript 3, PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, and CALS G4 support gives mixed-source document workflows several submission paths.
- Its stated six-color set includes Photo black, Matte black, and Gray for drawings that rely on more than black linework.
Not sure if the T1600 is right for you?
Compare key specs and an AI analyst read-out against similar models.
- Wide-format reach Prints up to 36" wide on rolls and sheets.
- Fine detail 2400 x 1200 DPI maximum resolution for crisp line work.
- Ink platform Cyan, Photo black, Matte black, Magenta, Yellow, Gray.
- Analyst score Scores 68/100 in our class-relative rating.
Overview
A six-ink 36-inch plotter built for overnight construction sets — and the color to match
The HP DesignJet T1600 Plus Edition is a 36-inch, six-ink thermal inkjet plotter aimed squarely at AEC production: bid sets, permit sets, as-builts and coordination drawings that mix crisp linework with color. It renders at 2400 x 1200 DPI using cyan, magenta, yellow, gray, matte black and photo black. That gray channel matters where it shows — in the soft tonal steps of a GIS map or a rendered elevation, where a printer working from black alone tends to go muddy in the last stretch toward shadow.
The PostScript designation is the reason to choose this variant. It brings PostScript 3 and PDF 1.7 handling, which is what keeps a complex, multi-layered Revit or AutoCAD PDF from dropping data or stitching incorrectly on a full plan set.
- Mid-to-high-volume architecture and engineering teams printing color coordination drawings
- Print rooms needing unattended overnight runs (HP rates the top stacker at up to 100 D-size sheets)
- MEP and civil work mixing fine linework with color-coded overlays
- IT-managed environments wanting HP Security Manager and Web Jetadmin
It is single-roll. If you routinely switch between bond and vellum mid-run, look to the dual-roll HP DesignJet T1600dr 36-in. If you need 44-inch width, the HP DesignJet T1700 44-in is the step up. Firms that don’t need PostScript can consider the HP DesignJet T1530 36-in.
- 36″Max print width
- 1,211 ft²/hRated speed
- 6Ink channels
- 2,400 dpiMax resolution
- 12 moIncluded warranty
Spec Analysis
overall
overall
At a glance
- Print width
- 36-in (up to 36" x 48" custom sizes)
- Ink set
- 6 inks — C, M, Y, Gray, Matte Black, Photo Black (HP 730)
- Max resolution
- 2400 x 1200 DPI
- Page description languages
- PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4
- Connectivity
- Wi-Fi Direct, direct printing, HP ePrint
- Software
- HP Click, Web Jetadmin, HP Security Manager, HP Build Workspace, optional HP SmartStream
- Footprint (W x D x H)
- 54.7" x 29.9" x 42.5"; 180.8 lbs
- Sustainability
- ENERGY STAR; 10 W sleep, 0.3 W off
Ideal for: mid-to-high-volume AEC teams printing mixed mono-and-color plan sets who need reliable PostScript/PDF handling and unattended overnight runs. Not the tool for: shops needing mid-run media switching (choose the T1600dr), 44-inch width (T1700), or firms that don’t need PostScript (T1530).
Expert analysis
What you should know
Key takeaways
- The 36-inch format and 2400 x 1200 DPI specification suit detailed AEC drawings and color-coded review documents.
- PostScript 3, PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, and CALS G4 support gives mixed-source document workflows several submission paths.
- Its stated six-color set includes Photo black, Matte black, and Gray for drawings that rely on more than black linework.
- The HP DesignJet T1600dr 36-in is the more relevant in-family choice when two loaded rolls are central to daily work.
- The supplied record does not state scanner or multifunction capability, so scan-copy workflows need separate validation.
A coordination sheet is not judged by its specification sheet. It is judged at the trailer table or in the studio pin-up: whether fine gray utilities stay separate, whether a revised cloud reads cleanly, and whether a PDF arrives without an argument about drivers. The HP DesignJet T1600 36-in PostScript Printer Plus Edition is a 36-inch color business printer built for that familiar AEC mix of CAD files, PDFs, HP-GL/2 drawings, raster references, and color-coded construction documents.
Its native page-description support is the practical story here. PostScript 3, PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, and CALS G4 support gives print-room and IT teams a broad submission path, while direct printing, Wi-Fi Direct, and HP ePrint offer useful alternatives for distributed project teams. At 2400 x 1200 DPI, it is specified for detailed linework and presentation-oriented output on the compatible media types listed below.
36"Maximum print width
2400 x 1200 DPIMaximum resolution
54.7"Printer footprint
180.8 lbsPrinter weight
Where the PostScript workflow earns its place
This machine is particularly well suited to architecture, engineering, surveying, and contractor teams that move between application-generated PDFs and established CAD plotting workflows. The supplied language set matters when jobs originate in different departments or from external consultants: a civil base map, MEP overlay, scanned reference, and final PDF do not all arrive in the same form. HP Click App, HP Click Driver for Windows 11, HP App, HP Web Jetadmin, HP Security Manager, HP Build Workspace, and optional HP SmartStream form the stated software ecosystem.
For IT, that combination supports a more managed environment than treating wide format as an isolated desktop peripheral. For operators, the important question remains mundane: can staff submit a correct sheet set reliably, with the intended page size and line weights? The available custom-media range runs from 210 x 279 to 36″ x 48″ (914 x 1219 mm), covering small-format check prints through full-width sheets. See how we assess printer performance in real workflows.
Use the estimator as a planning aid for repeatable output; real elapsed time also depends on job composition and handling between sheets.
One set: – · Weekly plotting time: –
Computed from the manufacturer's rated 1,211 ft²/h. Real-world mixed sets run slower — treat this as a best case for comparing machines, not a promise.
Color, media, and document detail
The six-color configuration uses Cyan, Photo black, Matte black, Magenta, Yellow, and Gray. That gray channel is relevant to AEC documents because much of the sheet lives between black linework and full color: screened structural backgrounds, grayscale aerial imagery, and layered coordination drawings. The eye notices these transitions in the quiet middle tones, where a pale utility layer can otherwise disappear into a gray base.
Compatible media types include bond, coated, matte, glossy, semi-glossy, satin, photo, and heavy paper. That makes the printer a sensible fit for ordinary plan output as well as selected review boards and image-containing sheets, provided the media choice reflects the job. The catalog lists HP 730 inks, HP 730F 300-ml Cyan DesignJet Ink Cartridge, HP 730F 300-ml Gray DesignJet Ink Cartridge, HP 730F 300-ml Magenta DesignJet Ink Cartridge, HP 730F 300-ml Yellow DesignJet Ink Cartridge, and the HP 727 printhead as compatible consumables. No measured ICC gamut data is available in the supplied record, so color-fidelity claims should be checked against the paper and files your team actually uses.
The family choice is really about media workflow
Choose this configuration when a 36-inch PostScript-capable device and broad file-language support match the work. It may be less appropriate for teams whose daily workload depends on keeping two rolls ready for different media or sizes; the HP DesignJet T1600dr 36-in is the in-family dual-roll alternative. Firms regularly issuing 44-inch documents should instead examine the HP DesignJet T1700 44-in, which provides a wider format.
Conversely, the HP DesignJet T1600 36-in is the nearer same-width family alternative for buyers assessing whether this PostScript-oriented configuration is necessary for their submission workflow. There is no scanner or multifunction capability stated in this product record, so organizations that need routine walk-up copying, mark-up capture, or archival scanning should validate that requirement separately rather than assuming it is included. Compare this printer with the dual-roll T1600dr.
Continue evaluating
HP DesignJet T1600dr 36-inThe same-width in-family alternative for a dual-roll workflow.HP DesignJet T1700 44-inA wider in-family option for teams that issue 44-inch documents.Compare T1600 PostScript Plus Edition and T1600drReview the two configurations side by side.See its class rankingPlace this machine in its broader wide-format category.
The read
The HP DesignJet T1600 36-in PostScript Printer Plus Edition is a credible AEC choice when file-language breadth, 36-inch output, and managed submission matter more than a dual-roll setup or integrated scanning. Its strengths align with mixed CAD/PDF environments and color-informed review documents; the trade-off is that teams with heavier media-switching or scan-copy requirements should select the configuration around the workflow, not simply the familiar DesignJet name.
Spec analysis
How the specs grade
Overall performance
within color graphics & photo printers · 12 compared
Class best 82 — Epson SureColor T5770DR
100% spec coverage
- This printer
- Epson SureColor T5770DR
Category leaders best color graphics & photo printers, by dimension
Verified specifications
The specs that decide it
| Maximum print width | 36 in |
|---|---|
| Maximum resolution | 2400 x 1200 DPI |
| Printing colors | Cyan, Photo black, Matte black, Magenta, Yellow, Gray |
| Number of print cartridges | 6 |
| Page description languages | PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4 |
Specifications
Full technical detail
Max resolution2400 x 1200 DPI
Max print width36"
ColorColor
Use caseCAD / Technical
Printing
| Color | Yes |
|---|---|
| Printing colors | Cyan, Photo black, Matte black, Magenta, Yellow, Gray |
| Resolution color | 2400 x 1200 DPI |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 6 |
| Page description languages | PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4 |
Performance
| HP segment | Business |
|---|---|
| Certification | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC) |
Paper handling
| Custom media sizes | 210 x 279 to 914 x 1219 mm |
|---|---|
| Paper tray media types | Coated paper, Semi-glossy paper, Glossy paper, Bond paper, Photo paper, Matte paper, Heavy paper, Satin paper |
| ISO A-series sizes (A0…A9) | A0, A1, A2, A3, A4 |
Ports & interfaces
| Wi-Fi Direct | Yes |
|---|---|
| Direct printing | Yes |
| Mobile printing technologies | HP ePrint |
Technical details
| Box contents | HP DesignJet T1600 Printer, printer stand and media bin, spindle(s)[6], printheads, introductory ink cartridges, user guide, power cords |
|---|
Weight & dimensions
| Depth | 29.9" (760 mm) |
|---|---|
| Width | 54.7" (1390 mm) |
| Height | 42.5" (1080 mm) |
| Weight | 180.8 lbs (82 kg) |
Power
| AC input frequency | 50/60 Hz |
|---|---|
| Power consumption (off) | 0.3 W |
| Power consumption (sleep) | 10 W |
Operational conditions
| Storage temperature (T-T) | -25 – 55 °C |
|---|---|
| Operating temperature (T-T) | 5 – 35 °C |
| Operating relative humidity (H-H) | 20 – 80% |
Other features
| UNSPSC-code | 43212104 |
|---|---|
| Electromagnetic compatibility | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC) |
Packaging data
| Package depth | 30.2" (767 mm) |
|---|---|
| Package width | 58.1" (1477 mm) |
| Package height | 31.5" (800 mm) |
| Package weight | 249.1 lbs (113 kg) |
| Bundled software | HP Click App, HP App, HP Web Jetadmin, HP Security Manager, HP Click Driver for Windows 11, HP Build Workspace, HP SmartStream (optional) |
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Brand-specific features
| HP GTIN (EAN/UPC) | 199896725903 |
|---|---|
| HP dynamic security | Yes |
Everything that fits the HP DesignJet T1600
The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.
12 ink cartridges · 18 paper & media items · 3 accessories · 12 coverage plans
HP DesignJet T1600 ink and paper →Supplies
Compatible ink, printheads & media
Genuine consumables that fit the HP DesignJet T1600 36-in PostScript Printer Plus Edition — only the cartridges, printheads and media compatible with this model.
Ink Cartridges 12
HP 730 300-ml Matte Black Ink Cartridge
HP 730 130-ml Cyan Ink Cartridge
HP 730 130-ml Matte Black Ink Cartridge
HP 730 300-ml Cyan Ink Cartridge
HP 730 300-ml Gray Ink Cartridge
HP 730 300-ml Photo Black Ink Cartridge
HP 730 300-ml Yellow Ink Cartridge
HP 730 300-ml Magenta Ink Cartridge
HP 730 130-ml Photo Black Ink Cartridge
HP 730 130-ml Gray Ink Cartridge
HP 730 130-ml Magenta Ink Cartridge
HP 730 130-ml Yellow Ink CartridgePaper & Media 12
Representative image10 Mil Water-resistant Blockout Display FilmRepresentative image11 Mil Water-Resistant Synthetic BannerRepresentative image15 Mil Water-Resistant Econo Scrim VinylRepresentative image16 Mil WR Opaque Scrim Vinyl (3″ AC)Representative image180gsm Solvent Satin PE PaperRepresentative image200gsm Special Matte Photo PaperRepresentative image230gsm Special Matte Photo PaperRepresentative image350g Vivid Matte Poly/Cotton CanvasRepresentative image380g Premium Matte Poly/Cotton CanvasRepresentative imageWSL 28LB Simple Inkjet Coated Matte Paper (C2S) (448)Representative image5 Mil Water-Resistant Self-Adh Vinyl (3" AC)Representative image6 Mil Water-Resistant Self-Adhesive PolypropyleneCoverage & Support Plans 6
Hp 3 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 1 (UC6M2E)Hp 3 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 2 (UC6N0E)
Hp 4 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 1 (UC6M3E)Hp 4 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 2 (UC6N1E)
Hp 5 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 1 (UC6M4E)Hp 5 Year Next Business Day Onsite Hardware Support W/Dmr For T1600 2 (UC6N2E)Questions
Straight answers
What does the PostScript / Plus Edition designation actually get me?
It adds PostScript 3 and PDF 1.7 processing, which matters for complex multi-layered Revit and AutoCAD PDFs — the kind that can otherwise drop data or stitch incorrectly across a plan set. HP also includes HP Build Workspace and updated security in the Plus Edition.
Can it run overnight construction-document sets unattended?
Yes. HP rates the integrated top stacker at up to 100 D-size sheets, which is designed to collect and flatten prints for unattended runs rather than dropping them into a catch-bin where they can scramble.
Does it handle both fine linework and color drawings well?
That’s its purpose. It reproduces at 2400 x 1200 DPI with a six-ink set that includes a dedicated gray, which helps tonal transitions in maps and renderings hold together instead of going flat in the shadows.
Is this a single-roll or dual-roll machine?
Single-roll. If you frequently switch media types mid-run — bond to vellum, for example — the dual-roll HP DesignJet T1600dr 36-in in the same family is the better fit.
What if I need wider than 36 inches?
Step up to the HP DesignJet T1700 44-in, or the dual-roll HP DesignJet T1700dr 44-in, for 44-inch output in the same product family.
What media and inks does it use?
It uses HP 730 inks and supports a broad range of coated, bond, vellum, glossy, matte and photo media — including Dietzgen bond, vellum and coated matte lines suited to engineering and CAD work.
