HP DesignJet 110plus nr

The paper paths are the useful part of this design. The automatic tray holds 150 sheets up to A2+, while manual feeding accepts larger sheets up to 25 x 64 inches. The rear path takes media up to 300 g/m2, which gives an in-house team a route for heavier presentation material without turning the ordinary tray into a science project. Roll media feeds through the rear path and has an automatic cutter.

For architects, engineers, surveyors, and construction teams, that means ordinary bond plans, a one-off D+ exhibit, a translucent technical sheet, or a short color map can stay in the office. Pigment-based black and dye-based color inks suit mixed technical and graphic output. Networked submission is possible through Ethernet, with USB available for direct connection. The control panel is deliberately simple: status lights, three keys, and information icons. There is not much to negotiate when a job needs attention.

Bottom line: It is most at home with intermittent, mixed-media technical printing rather than repetitive set production.

One roll, one input tray, and a 50-sheet output capacity put a clear boundary around unattended work. There is no duplex option. A crew printing several plan sets will be loading paper, collecting output, and watching the queue more than they should. The 64 MB of internal memory also belongs to an earlier workstation era, alongside listed support for Windows XP and older Mac operating systems. IT should validate driver availability, network policy, and the actual PDF workflow before putting this unit back into regular service.

The printer handles standard Letter through D+ sheet sizes and up to 24-inch rolls, but it is not a scanner or copier. Firms with frequent marked-up plan copying, archive intake, or 36-inch documents should look at the HP DesignJet T918 36-in instead. That is the meaningful in-family step-up listed here: wider media plus scanner/MFP capability. It is also listed as discontinued, so service and supply planning still deserve a hard look.

Bottom line: The failure mode is not poor line work; it is a modest paper-handling setup meeting a big deadline.

If this machine is already in service, its compact 41 x 21.1 x 8.66-inch body and 50.7-lb weight can make it practical to keep as a secondary plotter for occasional technical sheets. Confirm the condition of the ink system, cutter, paper paths, and network connection before assigning it deadline work. Compatible supplies listed for the unit include HP 10 and HP 11 ink families, plus Greenman H10B ink cartridge 1 pc(s) Black, Greenman H11C, Greenman H11M, and Greenman H11Y. Verify the required supply family against the installed machine before ordering.

For a 24-inch alternative, the Canon GP-200 24-in is a current catalog option. It should be evaluated on its own workflow fit, not treated as a like-for-like answer simply because the roll width matches. Use the side-by-side comparison to keep the discussion tied to media handling, connectivity, and the jobs that actually leave the print room.

Bottom line: Keep this model for light, local plotting if it is dependable; replace it when volume, scanning, wider sheets, or modern IT support become daily requirements.
