Overview
Epson SureColor SC-T3200-PS, Inkjet, 2880 x 1440 DPI, Cyan, Magenta, Matte black, Photo black, Yellow, A1 (594 x 841 mm), A1, A2, A3, A4, B2, B3
Expert analysis
Key takeaways
In an AEC office, the useful test is not a glossy rendering; it is whether a dense civil plan, a redlined coordination sheet, or a color-coded BIM export remains easy to read at the issue table. The current Epson SureColor SC-T3200 is a color inkjet wide-format printer for that practical middle ground: roll and cut-sheet output, Ethernet-connected submission, and support for HP-GL/2, HP-RTL, PostScript 3, and ESC/P-R workflows.
Its 2880 x 1440 DPI maximum resolution gives the machine a credible technical-document specification, while its five-color ink set includes matte black and photo black alongside cyan, magenta, and yellow. That combination is relevant when CAD linework, shaded site plans, and presentation-oriented boards share one device. The specification deserves context: resolution is only one part of readable output; file preparation, paper choice, and driver behavior still decide whether fine annotations arrive cleanly.
The SC-T3200 suits teams that need an in-house route for A1, A2, A3, and A4 documents, with roll paper for recurring plan output and cut sheets for occasional presentation or review work. Gigabit Ethernet provides a sensible shared-printer connection for a studio, engineering group, or site office with a stable wired network; there is also USB Type-B connectivity and direct printing. Wi-Fi is not included, so it is less natural for an office expecting ad hoc wireless submission.
For media, the stated thickness range is 0.003–0.059 inches. Compatible options include Epson Bond Paper Bright 90, 594mm x 50m, Epson Bond Paper White 80, 610mm x 50m, coated paper, presentation paper, and selected canvas media. For routine drawings, ordinary bond remains the operational baseline; coated and presentation media are better reserved for work where rendered fills and imagery matter.
HP-GL/2 and HP-RTL support matters in established CAD environments, while PostScript 3 can be useful where PDF-heavy output is part of the job stream. The 2.68-inch LCD provides local status access, and the printer has one RJ-45 port and one USB 2.0 port. Linux support is listed, alongside specified Windows and Mac operating systems; IT teams should validate their current operating-system and driver environment before deployment rather than treating a legacy OS listing as proof of present-day support.
The SC-T3200 can also be configured around broader document handling: the catalog lists an optional Epson MFP Scanner and an optional Epson Adobe Postscript 3 Expansion Unit. That is worth considering for firms that copy marked-up drawings or receive legacy paper plans. The trade-off is that a printer-plus-scanner workflow is not the same thing as a fully integrated production document system; confirm scanning, file-routing, and service responsibilities with the supplying partner.
This model is the practical choice when A1 output and a wired shared workflow are the requirement. Firms needing a more compact 24-inch format should examine the Epson SC-T3100 24-in. Those that regularly need a wider output format should look at the Epson SureColor T3270 36-in. The comparison is principally about output width and work pattern, not a simple hierarchy of image quality.
For buyers comparing nearby formats, the SC-T3200 and Epson SureColor T3270 36-in comparison is a useful starting point. If the decision is primarily driven by a need to scan and copy paper drawings, the Epson SC-T5200 38-in is also listed with scanner/MFP capability. Match the machine to the documents that actually leave your office, not merely the largest sheet size that appears once in a while.
Continue evaluating
The read
The Epson SureColor SC-T3200 is a grounded fit for AEC teams that need shared, wired color output for plan review, technical drawings, GIS-style mapping, and occasional presentation work up to its stated A1 maximum print size. Its roll and cut-sheet handling, five-color ink set, and CAD-relevant page-description languages make it more than a basic office printer. It is less appropriate for wireless-first deployment, teams that routinely require a wider format, or operations that need scanning as a core daily function. In those cases, compare the smaller Epson SC-T3100 24-in, the wider Epson SureColor T3270 36-in, or an MFP-oriented alternative before standardizing.
Spec analysis
Overall performance
within color graphics & photo printers
64% spec coverage
Verified specifications
| Print technology | Inkjet |
|---|---|
| Maximum resolution | 2880×1440manufacturer-verified |
| Print speed | 1 to 99 sheetsmanufacturer-verified |
| Printing colors | Photo Black, Matte Black, Yellow, Magenta, Cyanmanufacturer-verified |
| Page description languages | ESC/P raster (undisclosed command), HP-GL/2, HP RTLmanufacturer-verified |
| Internal memory | 1GB for Mainmanufacturer-verified |
| Maximum print size | A1 (594 x 841 mm) |
| Media thickness | 0.08 to 0.5manufacturer-verified |
| Wi-Fi | No |
| Ethernet | 10BASE-T, 100BASE-TX/1000BASE-Tmanufacturer-verified |
| Sound level (printing) | 50 dB |
| Power consumption | Approximately 52manufacturer-verified |
manufacturer-verified = checked against the manufacturer’s official datasheet, not aggregator data. Everything else is standards-body / catalog data we consider reliable.
Specifications
| Color | Yes |
|---|---|
| Printing colors | Cyan, Magenta, Matte black, Photo black, Yellow |
| Print technology | Inkjet |
| Maximum resolution | 2880 x 1440 DPI |
| Display | LCD |
|---|---|
| RAM capacity | 1 GB |
| Product color | Gray |
| Built-in display | Yes |
| Display diagonal | 2.7" |
| Country of origin | China |
| Sound pressure level (printing) | 50 dB |
| Maximum print size | A1 (594 x 841 mm) |
|---|---|
| ISO A-series sizes (A0…A9) | A1, A2, A3, A4 |
| JIS B-series sizes (B0…B9) | B2, B3 |
| Wi-Fi | No |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Depth | 32" (813 mm) |
|---|---|
| Width | 41.3" (1050 mm) |
| Height | 44" (1117 mm) |
| Weight | 147.7 lbs (67 kg) |
| Power supply | 52 W |
|---|---|
| Power consumption (off) | 0.5 W |
| Power consumption (standby) | 3 W |
| Copying | No |
|---|
| Scanning | No |
|---|
| Quantity per pack | 1 pc(s) |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Manual | Yes |
|---|---|
| Package depth | 46.1" (1170 mm) |
| Package width | 49" (1245 mm) |
| Package height | 31.9" (810 mm) |
| Package weight | 3.51 oz (99.5 g) |
| Drivers included | Yes |
| Windows operating systems supported | Yes |
|---|
Everything that fits the Epson SureColor SC-T3200
The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.
8 ink cartridges · 34 paper & media items · 7 accessories · 7 coverage plans
Epson SureColor SC-T3200 ink and paper →Supplies
Genuine consumables that fit the Epson SureColor SC-T3200-PS (with Adobe Postscript Unit) — only the cartridges, printheads and media compatible with this model.
Epson Enhanced Matte Posterboard, 24" x 30", 1130g/m²
Epson Singlepack UltraChrome XD YellowT693400(350ml)
Epson Singlepack UltraChrome XD MagentaT694300(700ml)
Epson Singlepack UltraChrome XD YellowT694400(700ml)
Epson Singlepack UltraChrome XD CyanT692200(110ml)
Epson Singlepack UltraChrome XD MagentaT692300(110ml)
Epson Single pack UltraChrome XD Cyan T693200 (350ml)
Epson Singlepack UltraChrome XD YellowT692400(110ml)
Representative imageMagic 98gsm/26# Coated Matte Paper (DMPG98)Representative image20LB Inkjet Vellum (772)Representative image18LB Inkjet Bond Paper (Translucent) (750)Representative image28LB Inkjet Coated Matte Paper (748)Representative image46LB Inkjet Coated Matte Paper (747)Representative image6.5mil Matte Coated Paper w/ PSA (746PSA)Representative image20LB High Brite Inkjet Bond Paper (740)Representative image24LB Inkjet Bond Paper (731)Representative image20LB Inkjet Bond Paper (730)Representative image24LB Inkjet Coated Matte Paper Economy (714)Representative image20LB Engineering Vellum (471)Representative imageWSL 28LB Simple Inkjet Coated Matte Paper (C2S) (448)
Epson Water Color Paper – Radiant White Roll, 24" x 18 m, 190g/m²
Epson Premium Glossy Photo Paper Roll, 329 mm x 10 m, 255g/m²
Epson Premium Canvas Satin, 17" x 3 m, 350g/m²
Epson Premium Canvas Satin, 24" x 12,2 m, 350g/m²
Epson Singleweight Matte Paper, DIN A2, 120g/m², 100 Sheets
Epson WaterResistant Matte Canvas Roll, 24" x 12,2 m, 375g/m²
Epson WaterResistant Matte Canvas Roll, 13" x 6,1 m, 375g/m²
Epson WaterResistant Matte Canvas Roll, 17" x 2,1 m, 375g/m²
Epson Singleweight Matte Paper, DIN A3+, 120g/m², 100 Sheets
Epson Matte Backlit Film, 24" x 30,5 m, 280g/m²
Epson Bond Paper White 80, 610mm x 50m
Epson Bond Paper Bright 90, 594mm x 50m
Epson Bond Paper Bright 90, 610mm x 50m White Matte
Epson Bond Paper Satin 90, 610mm x 50m
Epson Coated Paper 95, 610mm x 45m
Epson Presentation Paper HiRes 120, 610mm x 30m
Epson Presentation Paper HiRes 180, 610mm x 30m
Epson Bond Paper White 80, 594mm x 50m
Epson Production Canvas Matte, 610mm x 12,2m
Epson Production Canvas Matte, 914mm x 12,2m
Epson Production Photo Paper Glossy 200 24" x 30m
Epson Production Photo Paper Semigloss 200 24" x 30m
Epson 1-Year Next-Business-Day On-Site Purchase With Hardware Extended Service P (PST3200S1)
Epson 2-Year Next-Business-Day On-Site Purchase With Hardware Extended Service P (PST3200S2)
Epson 03 years CoverPlus+ Onsite service including Print Heads for SureColour SC-T3200
Epson 04 years CoverPlus+ Onsite service including Print Heads for SureColour SC-T3200
Epson 4-Year Next-Business-Day On-Site Purchase With Hardware Extended Service P (PST3200S4)
Epson 05 years CoverPlus+ Onsite service including Print Heads for SureColour SC-T3200
Epson 1E years extension to CoverPlus+ Onsite service including Print Heads for SureColour SC-T3200Questions
It supports HP-GL/2 and HP-RTL, along with PostScript 3 and ESC/P-R. That makes it relevant to CAD-oriented and PDF-based AEC document workflows, subject to validation with your current applications and drivers.
It accepts roll paper and cut sheets, with a stated media-thickness range of 0.003–0.059 inches. Listed compatible media include Epson bond, coated, presentation, and selected canvas options.
Yes. It has one Gigabit Ethernet RJ-45 connection and supports 10, 100, and 1000 Mbit/s Ethernet rates. It does not include Wi-Fi.
An Epson MFP Scanner is listed as an accessory. Buyers should confirm the desired scanner configuration, stand, workflow integration, and local service arrangement before purchase.
Consider it when your work routinely requires a wider 36-inch output format. The SC-T3200 is better aligned with its stated A1 maximum print size and a more compact AEC document role.
