HP DesignJet H35100
wide-format inkjet printer
- ModelH35100
Authorized HP dealerGenuine hardware & ink
Manufacturer warrantyExtension plans available
Free shippingContinental U.S.
Plotter specialistsAEC experts, not just sellers
Analyst take
- Prints roll-fed graphics up to 54 in wide and up to 96 in long — full presentation boards without tiling.
- Feeds banner vinyl, adhesive vinyl, canvas, backlit film and photo paper, not everyday bond drawings.
- Runs on the HP 788 ink family with a deep list of matched HP roll media.
Not sure if the H35100 is right for you?
Compare key specs and an AI analyst read-out against similar models.
Overview
Built for the work
HP DesignJet H35100 EU Printer, Roll-fed materials such as banner vinyl, adhesive vinyl, canvas, paper, and backlit film, CE, Input voltage: 200 to 240 V ac, single phase, 50/60 Hz, 16 A max, CE, 24 to 54 in wide; up to 96 in long, 7-in color touchscreen
Expert analysis
What you should know
Key takeaways
- Prints roll-fed graphics up to 54 in wide and up to 96 in long — full presentation boards without tiling.
- Feeds banner vinyl, adhesive vinyl, canvas, backlit film and photo paper, not everyday bond drawings.
- Runs on the HP 788 ink family with a deep list of matched HP roll media.
- Requires a 200–240V single-phase, 16 A circuit — confirm facilities power before delivery.
- This is a signage and presentation device, not a plan plotter for permit sets or as-builts.
- A 7-in color touchscreen keeps job setup at the machine instead of on a laptop.
Let’s be honest about what this machine is before anyone at the front desk mistakes it for the plotter that runs the bid set. The HP DesignJet H35100 is a wide-format roll printer built for banner vinyl, adhesive vinyl, canvas, backlit film and photo-grade paper — the presentation and signage side of an AEC shop, not the D-size permit set you’re collating at 4:45 p.m.
Think ribbon-cutting boards. Site-hoarding graphics. The rendered elevation the principal wants mounted for the client walkthrough. That’s the job standing at this output tray.
24 to 54 in wideMedia widthup to 96 in long — full presentation boards without tiling
7-in color touchscreenControl paneljob setup at the machine, no laptop tether
200 to 240 V ac, single phase, 50/60 Hz, 16 A maxPowerthis is a 208–240V circuit, not a wall outlet
HP 788Inkthe ink family this machine runs on
What it actually does well
The width is the story. Up to 54 in wide and up to 96 in long means you print a full presentation board or a stretch of site graphics in one pass. No tiling. No taping seams that show up under gallery lights in front of the client.
The media list is where it separates itself from a plan printer. Banner vinyl, adhesive vinyl, canvas, backlit film, paper. That’s a signage and display feed, not a bond-paper feed. You’re producing things that get mounted, hung, wrapped around a hoarding, or lit from behind in a lobby.
The 7-in touchscreen keeps job setup at the machine. Whoever’s loading the roll can set it up without hunting for a driver on someone’s laptop.
Where it is NOT the right tool
Here’s the part that saves you a bad purchase. This is not your everyday plan plotter. If your daily grind is D-size and E-size drawings — permit sets, redlines, as-builts, bid packages — this machine is the wrong department entirely. It’s a color graphics device fed by rolls of vinyl and film, not the printer you want spitting out fifty monochrome sheets before a submittal deadline.
For that CAD and document work, a plan-oriented machine like the HP DesignJet T918 36-in — an MFP-class plotter with a scanner — is the tool that matches the job, though note it’s discontinued and now lives mostly in the installed base. Want to see them side by side? Compare the H35100 against the T918 and the split is obvious: one prints presentations, the other runs the deadline.
The other practical note: power. This wants a 208–240V single-phase circuit at up to 16 A. Confirm that with your facilities people before delivery day, not after.
Consumables and feeding it
It runs on the HP 788 ink family. On the media side there’s a deep bench of HP roll stock resolved for this machine — from the HP CG415A large format media 45.7 m and HP CG435A large format media through gloss options like the HP CG448A large format media 25 m High-gloss, film such as the HP CG424A printing film, and photo stocks including the HP CG420A photo paper. Whatever the presentation calls for, there’s a matched roll for it.
Keep reading
The read
Buy this for what it is: a wide roll-fed graphics and signage printer that turns renderings, boards, banners and backlit film into finished output up to 54 in wide and 96 in long. It earns its footprint in a firm that produces client-facing display work regularly. If your real problem is stacks of drawings before a submittal, this isn’t it — you want a plan plotter, and you should shop accordingly. Match the machine to the job standing at the tray. Bottom line: right printer for the lobby, wrong printer for the deadline.
Spec analysis
How the specs grade
Overall performance
—Not enough data for an overall score
Individual dimensions are shown where the specs support them.
Specifications
Full technical detail
Use caseCAD / Technical
Performance
| Certification | CE |
|---|
Paper handling
| Custom media sizes | 24 to 54 in wide; up to 96 in long |
|---|---|
| Media types supported | Roll-fed materials such as banner vinyl, adhesive vinyl, canvas, paper, and backlit film |
Power
| Power requirements | Input voltage: 200 to 240 V ac, single phase, 50/60 Hz, 16 A max |
|---|
Other features
| Safety | CE |
|---|---|
| Control panel | 7-in color touchscreen |
Everything that fits the HP DesignJet H35100
The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.
7 ink cartridges · 26 paper & media items
HP DesignJet H35100 ink and paper →Supplies
Compatible ink, printheads & media
Genuine consumables that fit the HP DesignJet H35100 EU Printer — only the cartridges, printheads and media compatible with this model.
Ink Cartridges 7
Paper & Media 26
HP Q8684AE printing film
HP Q8685AE printing film
HP UV Premium Photobase Paper-1372 mm x 30.5 m (54 in x 100 ft)
HP Mesh Banner-1067 mm x 25 m (42 in x 82 ft)
HP CG415A large format media 45.7 m
HP Photo-realistic Poster Paper-914 mm x 61 m (36 in x 200 ft) large format media Satin
HP Outdoor Frontlit Scrim Banner-1067 mm x 35 m (42 in x 115 ft)
HP Outdoor Frontlit Scrim Banner-1372 mm x 35 m (54 in x 115 ft)
HP HDPE Reinforced Banner-914 mm x 45.7 m (36 in x 150 ft) large format media Matte
HP CG423A self-adhesive vinyl Permanent High-gloss
HP CG424A printing film
HP CG435A large format media
HP CG439A large format media
HP CG420A photo paper
HP CG440A large format media
HP CG502A photo paper Satin
HP CG454A printing film
HP CG453A printing film
HP DuPont Tyvek Banner-914 mm x 30.5 m (36 in x 100 ft) large format media Semi-gloss
HP CG449A large format media 25 m High-gloss
HP CG445A large format media
HP CG448A large format media 25 m High-gloss
HP CH001A photo paper
HP CH003A large format media
HP CH005A printing film
HP CH010A photo paperQuestions
Straight answers
Is the H35100 a good everyday plan plotter for D- and E-size drawings?
No. It’s a roll-fed color graphics printer built for vinyl, canvas, film and photo media. For permit sets, redlines and as-builts you want a plan-oriented plotter instead.
What media can it actually print on?
Roll-fed materials including banner vinyl, adhesive vinyl, canvas, paper and backlit film, with a wide range of matched HP roll stocks resolved for the machine.
How wide and how long can it print?
It handles custom media from 24 to 54 in wide and up to 96 in long, so a full presentation board prints in one pass without tiling.
What ink does it use?
It runs on the HP 788 ink family.
What are the power requirements?
200 to 240 V ac, single phase, 50/60 Hz, at up to 16 A. That’s a 208–240V circuit — confirm the outlet with facilities before delivery.
How do I compare it to a document plotter in the same family?
Look at the discontinued HP DesignJet T918 36-in, an MFP-class plan plotter with a scanner. It handles the CAD and document side; the H35100 handles graphics and signage. They solve different problems.
