Analyst take
- Floor-standing wide-format printer aimed at combined plan and presentation output.
- UV pigment color needs the HP UV Upgrade Kit with Ink/42 or Ink/60 — it's an add-on, not standard.
- Uses the older HP 83 ink and multi-printhead system, which demands more operator upkeep.
Not sure if the 5000ps UV is right for you?
Compare key specs and an AI analyst read-out against similar models.
Overview
Built for the work
HP DesignJet 5000ps UV Printer
Expert analysis
What you should know
Key takeaways
- Floor-standing wide-format printer aimed at combined plan and presentation output.
- UV pigment color needs the HP UV Upgrade Kit with Ink/42 or Ink/60 — it's an add-on, not standard.
- Uses the older HP 83 ink and multi-printhead system, which demands more operator upkeep.
- Supports a wide media list including vellum, photo, satin, backlit film and canvas.
- No built-in scanner or copier — not a multifunction machine.
- Most relevant today as an installed-base unit rather than a new purchase.
It’s 4:45 on a bid day. Somebody needs a set of D-size plans and a color rendering for the lobby wall, and they need both before the courier leaves. The HP DesignJet 5000ps UV was built for exactly that kind of split personality: line-work plotter by day, presentation printer when the pitch matters.
This is an older machine. You’ll find it in reprographics rooms and larger AEC shops that bought into it years ago and kept it running. If you’re looking at one today, you’re almost certainly evaluating a used unit or keeping an installed one alive — so the real questions are about consumables, service and whether it still earns its floor space.
HP 83Ink systemsix-color dye/UV pigment set
HP UV Upgrade Kit with Ink/42UV pigment optionfor longer-life color output
HP Vellum Paper-610 mm x 45.7 m (24 in x 150 ft)Roll media exampleone of many supported rolls
What it actually does well
The draw here was always the UV pigment path. With the HP UV Upgrade Kit with Ink/42 or the larger HP UV Upgrade Kit with Ink/60, the 5000ps could produce color output meant to hold up longer than standard dye work — useful when a rendering or a color-coded coordination drawing needs to survive a job-trailer wall or a client’s office.
Media range is the other strength. This machine feeds a long list of surfaces: bond and coated for everyday plots, HP Vellum Paper for reproducibles, and photo and satin stocks like HP Premium Instant-dry Satin White and HP Photo Imaging Gloss White for presentation boards. Backlit film and canvas are in the compatible list too. That flexibility is why it landed in shops that print more than just plan sets.
Where it doesn't fit anymore
Be honest about the age. The HP 83 ink and printhead architecture is a generation behind current DesignJet plumbing, and the six separate printheads plus their cleaning routine mean more operator attention than a modern cartridge-and-integrated-head machine. Budget time for maintenance, not just printing.
There’s also no scanner or copy path on this unit. If your workflow leans on scanning redlines, copying as-builts or handling walk-up jobs, you want a multifunction machine instead. The discontinued HP DesignJet T918 36-in is the in-family reference point for an MFP-style workflow — see the side-by-side if scanning is on your list.
And color longevity is a want, not a need, for a lot of AEC shops. If you print monochrome plan sets all day and rarely touch a rendering, the UV upgrade is spend you won’t recover.
Keep reading
The read
The 5000ps UV made sense for a shop that needed both plan output and durable color from one floor-standing machine, and its media range still earns respect. But it’s an older platform with a printhead-heavy maintenance load and no scanning. Keep one running if it’s paid for and your operator knows its habits. If you’re buying fresh, or you need scan-and-copy, look at a current or MFP-capable model instead — the UV color trick isn’t worth an aging platform unless presentation work is a real, recurring part of your day. Bottom line: a capable veteran, best kept in service rather than newly acquired.
Spec analysis
How the specs grade
Overall performance
—Not enough data for an overall score
Individual dimensions are shown where the specs support them.
Specifications
Full technical detail
Use caseCAD / Technical
Everything that fits the HP DesignJet 5000ps UV
The full supplies hub lists every cartridge, printhead, roll and accessory verified against the manufacturer's own documentation for this machine.
6 ink cartridges · 18 printheads · 123 paper & media items · 3 accessories
HP DesignJet 5000ps UV ink and paper →Supplies
Compatible ink, printheads & media
Genuine consumables that fit the HP DesignJet 5000ps UV Printer — only the cartridges, printheads and media compatible with this model.
Ink Cartridges 6
Printheads 18
HP Cartouche d'encre magenta UV 83 (680 ml) print head Thermal inkjet
HP 83 Cyan UV Printhead and Printhead Cleaner
HP 83 Yellow UV Printhead and Printhead Cleaner
HP 83 Light Cyan UV Printhead and Printhead Cleaner
HP Cartouche d'encre cyan UV 83 (680 ml) print head Thermal inkjet
HP Cartouche d'encre cyan clair UV 83 (680 ml) print head Thermal inkjet
HP Cartouche d'encre magenta clair UV 83 (680 ml) print head Thermal inkjet
HP 83 Black UV Printhead and Printhead Cleaner
HP Cartouche d'encre UV noire 83 680 ml print head Thermal inkjet
HP 83 Magenta UV Printhead and Printhead Cleaner
HP 83 Light Magenta UV Printhead and Printhead Cleaner
HP 83 3-pack 680-ml Black UV Cartridges print head Thermal inkjet
HP 83 3-pack 680-ml Cyan UV Cartridges print head Thermal inkjet
HP 83 3-pack 680-ml Magenta UV Cartridges print head Thermal inkjet
HP 83 3-pack 680-ml Yellow UV Cartridges print head Thermal inkjet
HP 83 3-pack 680-ml Light Cyan UV Cartridges print head Thermal inkjet
HP 83 3-pack 680-ml Light Magenta UV Cartridges print head Thermal inkjet
HP Cartouche d'encre jaune UV 83 (680 ml) print head Thermal inkjetPaper & Media 123
HP Sahara Fine Art Paper 140 g/m²-36"/914 mm x 10.7 m large format media
HP Q1733A printing paper Matte 1 sheets White
HP Q1734A large format media 22.9 m
HP Two-view Cling Film
HP Two-view Cling Film
HP 3M Matte Overlaminate Paper-1372 mm x 22.9 m (54 in x 75 ft)
HP C6779A printing film
HP C6780A large format media 30.5 m
HP C6568B large format media 45.7 m
HP Q1408A plotter paper
HP Durable Image Gloss UV Paper-914 mm x 22.9 m (36 in x 75 ft)
HP Durable Image Gloss UV Paper-1372 mm x 28 m (54 in x 90 ft)
HP Q1430A photo paper Brown, White
HP C6964A photo paper White Gloss
HP White Matte Polyester Film
HP White Matte Polyester Film 165 g/m²-60"/1524 mm x 15.2 m
HP Photo Imaging Satin Paper-1524 mm x 30.5 m (60 in x 100 ft)
HP RC Satin Proofing Paper-914 mm x 22.9 m (36 in x 75 ft)
HP Q1420A photo paper Brown, White
HP Universal Satin White
HP Vellum Paper-610 mm x 45.7 m (24 in x 150 ft)
HP Q1760A large format media 45.7 m Matte
HP 3M Matte Overlaminate Paper
HP Studio Canvas-914 mm x 10.7 m (36 in x 35 ft)
HP C6570C large format media 30.5 m
HP Outdoor Paper 145 g/m²-60"/1524 mm x 30.5 m large format media
HP Matte Polypropylene 1372 mm x 22.9 m (54 in x 75 ft)
Representative imageHP Bright White Inkjet Paper, 36 in x 300 ft (C6810A)
HP Aquarella Art Paper 240 g/m²-36"/914 mm x 10.7 m large format media
HP 3M Lustre Overlaminate Paper
HP Reverse Print Matte Backlit Film
HP C6035A large format media 45.7 m
HP C6036A printing paper Matte White
HP C6567B plotter paper
HP White Glossy Opaque Polyester Film-1067 mm x 15.2 m (42 in x 50 ft)
HP Universal Semi-gloss Photo Paper
HP C3860A printing paper White
HP C6789A large format media 15.2 m
HP C6777A printing film
HP Q1718A large format media 10.7 m
HP Clear Film 174 gsm-610 mm x 22.9 m (24 in x 75 ft)
HP Durable Image Gloss UV Paper-1524 mm x 28 m (60 in x 90 ft)
HP C7950A large format media 30.5 m Matte
HP White Glossy Opaque Polyester Film 170 g/m²-36"/914 mm x 15.2 m
HP Q1904A printing film
HP Matte Polypropylene 1524 mm x 22.9 m (60 in x 75 ft)
HP Q1421A photo paper Brown, White
HP Q1757A printing paper Matte Yellow
HP Reverse Print Matte Backlit Film
HP Reverse Print Matte Backlit Film
HP Matte Canvas 340 g/m²-24"/610 mm x 10.7 m large format media
HP Matte Canvas 340 g/m²-36"/914 mm x 10.7 m large format media
HP Q1724A large format media 10.7 m Matt
HP Q1416A large format media 30.5 m
HP Photo Imaging Gloss White
HP Outdoor Paper 145 g/m²-54"/1372 mm x 30.5 m large format media
HP Q1745A large format media 10 m Matte
HP C6787A large format media 15.2 m
HP Q1743A printing paper Matte 1 sheets White
HP Q1735A large format media 22.9 m
HP C6778A large format media Matte
HP Studio Canvas-1372 mm x 10.7 m (54 in x 35 ft)Representative imageHP Heavyweight Coated Paper, 42 in x 100 ft (C6569C)
HP Photo Imaging Gloss White
HP Q1730A large format media 30.5 m
HP polyester film opaque, white glossy (1372 mm roll)
HP White Matte Polyester Film 165 g/m²-54"/1372 mm x 15 m
HP Q1908A printing film
HP C6959A photo paper White
HP C6960A photo paper Satin
HP RC Satin Proofing White
HP Universal Semi-Gloss Photo Paper
HP C3861A large format media 45.7 m Matte
HP Adhesive Vinyl 914 mm x 12.2 m (36 in x 40 ft)
HP Productivity Gloss Photo Paper-1067 mm x 30.5 m (42 in x 100 ft)
HP Productivity Gloss Photo Paper-1372 mm x 30.5 m (54 in x 100 ft)
HP Productivity Gloss Photo Paper-1524 mm x 30.5 m (60 in x 100 ft)
HP Productivity Semi-gloss Photo Paper-914 mm x 30.5 m (36 in x 100 ft)
HP Productivity Semi-gloss Photo Paper-1067 mm x 30.5 m (42 in x 100 ft)
HP Productivity Semi-gloss Photo Paper-1372 mm x 30.5 m (54 in x 100 ft)
HP Productivity Semi-gloss Photo Paper-1524 mm x 30.5 m (60 in x 100 ft)
HP Q1956A large format media 67.5 m
HP Heavyweight Coated 1524 mm x 68.5 m (60 in x 225 ft) large format media Matte
HP Q1961A large format media
HP Q1962A large format media
HP C7949A large format media 30.5 m Matte
HP Two-view UV Cling Film 254 g/m²-36"/914 mm x 22.9 m large format media
HP Two-view UV Cling Film 254 g/m²-42"/1067 mm x 22.9 m large format media
HP Durable Scrim-1067 mm x 12.2 m (42 in x 40 ft)
HP Durable Scrim 550 g/m²-24"/610 mm x 12.2 m large format media
HP Q2524B large format media 12.2 m
HP Durable Scrim 550 g/m²-36"/914 mm x 12.2 m large format media
HP Q1902B large format media
HP Q1901B large format media 15.2 m
HP Q1898B large format media
HP Q1899B large format media
HP Durable Scrim 550 g/m²-54"/1372 mm x 12.2 m large format media
HP Universal Semi-gloss Photo Paper-1270 mm x 30.5 m (50 in x 100 ft)
HP Q6579A photo paper Brown, White
HP Q6580A photo paper Matte
HP Q6581A photo paper
HP Q6583A photo paper Brown, White
HP Q6578A photo paper Brown, White
HP Q6588A large format media Matte
HP Q6596A large format media Matte
HP Q1441A large format media 45.7 m
HP Q1442A large format media 45.7 m
HP Q1444A printing paper Matte
HP Q1445A printing paper Matte
HP Q7999A photo paper
HP Q8677A printing film
HP Universal Adhesive Vinyl 914 mm x 20 m (36 in x 66 ft)
HP Q8673A large format media 6.1 m
HP Collector Satin Canvas-610 mm x 6.1 m (24 in x 20 ft)
HP Q8713A photo paper Matte
HP Q7990A photo paper Gloss
HP Premium Instant-dry Satin White
HP Q7991A photo paper
HP Aquarella Fine Art Paper-914 mm x 10.7 m (36 in x 35 ft)
HP Aquarella Art Paper-610 mm x 10.7 m (24 in x 35 ft)
HP Hahnemühle Smooth Fine Art Paper 265 g/m²-1067 mm x 10.7 m (42 in x 35 ft)
HP Hahnemühle Textured Fine Art Paper 265 g/m²-1067 mm x 10.7 m (42 in x 35 ft)
HP Q8750A printing film
Questions
Straight answers
Does the 5000ps do UV-durable color out of the box?
No. UV pigment color comes from the HP UV Upgrade Kit with Ink/42 or the larger HP UV Upgrade Kit with Ink/60. Standard configurations use the HP 83 dye-based set.
Can it scan or copy?
No. This is a print-only machine. If you need to scan redlines or copy as-builts, look at an MFP such as the discontinued HP DesignJet T918 36-in.
What inks and printheads does it use?
It runs the HP 83 ink and printhead family, a multi-printhead system that requires more routine maintenance than modern integrated-head DesignJets.
What media can it handle?
A broad range — bond, coated, HP Vellum Paper, HP Premium Instant-dry Satin White, HP Photo Imaging Gloss White, backlit film and canvas among others.
Should I buy one new today?
It’s an older, largely installed-base platform. Keeping a paid-for unit running can make sense, but for a fresh purchase — especially if you need scanning — a current or MFP-capable model is the better path.
