10 mil Contract Proof Paper (GRACoL 2006)
- ModelPROLINET1
Representative imageA generic photograph of wide-format roll media and our shipping carton. It is not a photograph of this product, and it does not show the pack quantity, roll length, width or colour you are ordering — those are in the title and the size options below.
Genuine OEM hardwareAuthorized U.S. distribution
Manufacturer warrantyExtension plans available
Free shippingContinental U.S.
Plotter specialistsAEC experts, not just sellers
Specifications
Dye· BESTPigment· BEST3″ core
A 10-mil, 250 gsm satin contract proof paper targeted at the GRACoL 2006 characterisation data set. Measured at 95% opacity, 90 brightness and 92 CIE whiteness, which is a restrained white by wide-format standards. Rated BEST for aqueous dye and aqueous pigment inks. Supplied in 44-inch rolls on 3-inch cores.
| Media type | Proofing › Satin Proofing |
|---|---|
| Finish | Satin |
| Thickness | 10 mil |
| Weight | 250 gsm |
| Core size | 3" core |
Overview
Built for the work
A 10-mil, 250 gsm satin contract proof paper targeted at the GRACoL 2006 characterisation data set. Measured at 95% opacity, 90 brightness and 92 CIE whiteness, which is a restrained white by wide-format standards. Rated BEST for aqueous dye and aqueous pigment inks. Supplied in 44-inch rolls on 3-inch cores.
Expert analysis
What you should know
PROLINET1 is a satin contract proof paper — 10 mil, 250 gsm — targeted at GRACoL 2006. A contract proof is not a presentation print; it is the reference a printer and a client both sign against, so the paper’s job is to be predictable rather than impressive.
What Dietzgen 10mil Contract Proof Paper (PROLINET1) is used for
- Contract proofing
- GRACoL 2006 colour matching
- Prepress sign-off proofs
All three are the same job stated three ways, which tells you this is a single-purpose stock rather than a general shop roll. It is named to a specific characterisation data set — GRACoL 2006 — so the check before ordering is whether that is the target your press is being held to. Dietzgen makes separate proofing papers aimed at GRACoL 2013 and at FOGRA.
Ink compatibility
Two chemistries are rated, both BEST: aqueous dye and aqueous pigment. Nothing else is rated — no latex, no solvent, no UV, no toner, no HP PageWide. That is exactly right for the application. Contract proofing is done on aqueous inkjet proofers, and a proofing paper has no reason to spread its coating across chemistries it will never meet.
Working with it
The measured optical values are where a proof paper earns its keep. PROLINET1 reads 95% opacity, 90 brightness and 92 CIE whiteness. That whiteness figure sits well below the 120 to 150 CIE range Dietzgen’s display and coated-matte papers occupy, and a restrained white is closer to the commercial stock the job will actually print on. It is supplied in a single 44-inch roll width on 3-inch cores.
Specifications
Full technical detail
